How do I add bay windows?

1. Click on Utilities Button at the top of the ArtiCAD screen, this will load up with a drop-down Menu.

2. Click on Tools, then click on Useful Wizards, this will load up the Select Wizard to Run box.

3. Within this box will be an option for Add Bay Window, select this option and click on OK.

4. A box will load up with a diagram of three different Style Bay Windows to choose from.

5. After selecting one of the three options and clicked on OK, you will be able to choose the Width, Depth and how many Windows are in the Bay Window.
